Appendix E. List of Accessories
E_
2. UC-DN01Z-01A and UC-DN01Z-02A can be used as the main-line cable as well as the branch-line
cable. The maximum communication distances that they support are different.
The maximum communication distances the two cables support at different DeviceNet transmission
speed are displayed as follows.
DeviceNet transmission speed（bit/s）
125K 250K 500K
Max. communication distance for
UC-DN01Z-01A
（
m
）
500 250 100
Max. communication distance for
UC-DN01Z-02A
（
m
）
100 100 100
3. The maximum communication distance at a transmission speed is regulated in the DeviceNet
protocol. The relationships between maximum communication distances and transmission speeds
are shown in the following table.
Transmission speed
（
bit/s
）
10K 20K 50K 125K 250K 500K
Max. communication
distance
（
m
）
5000 2500 1000 500 250 100

Distribution box
Model
Circuit figure
TAP-CN01
T
B
1
T
B
2
T
h
ic
k
C
a
b
le
T
h
ic
k
C
a
b
le
V+ V+
H H
S S
L L
V- V-
V+
H
S
L
V-
1
2
1
Ώ
TB3
Thin Cable
TAP-CN02
TB1
TB2
TB5
TB3
TB4
Thick Cable
Thick Cable
Thin Cable
Thin Cable
V+ V+ V+
H H H
S S S
L L L
V- V- V-
V+V+
H HSS L
L
V-
V-
1
2
1
Ώ
Thin Cable
E-5
