ASDA A2-E Chapter 6 Object Dictionary Entries
Revision April, 2015 6-31
Object 60B8
h
: Touch probe function
INDEX 60B8
h
Name Touch probe function
Object Code VAR
Data Type UNSIGNED16
Access RW
PDO Mapping Yes
Value Range UNSIGNED16
Default Value 0
Comment 0
Object 60B9
h
: Touch probe status
INDEX 60B9
h
Name Touch probe status
Object Code VAR
Data Type UNSIGNED16
Access RO
PDO Mapping Yes
Value Range UNSIGNED16
Default Value 0
Comment 0
Object 60BA
h
: Touch probe pos1 pos value
INDEX 60BA
h
Name Touch probe pos1 pos value
Object Code VAR
Data Type INTEGER32
Access RO
PDO Mapping Yes
Value Range INTEGER32
Default Value 0
Comment Unit: PUU
