Delta ASDA A2-E

Chapter 6 Object Dictionary Entries ASDA A2-E
6-32 Revision April, 2015
Object 60BB
h
: Touch probe pos1 neg value
INDEX 60BB
h
Name Touch probe pos1 neg value
Object Code VAR
Data Type INTEGER32
Access RO
PDO Mapping Yes
Value Range INTEGER32
Default Value 0
Comment Unit: PUU
Object 60BC
h
: Touch probe pos2 pos value
INDEX 60BC
h
Name Touch probe pos2 pos value
Object Code VAR
Data Type INTEGER32
Access RO
PDO Mapping Yes
Value Range INTEGER32
Default Value 0
Comment Unit: PUU
Object 60BD
h
: Touch probe pos2 neg value
INDEX 60BD
h
Name Touch probe pos2 neg value
Object Code VAR
Data Type INTEGER32
Access RO
PDO Mapping Yes
Value Range INTEGER32
Default Value 0
Comment Unit: PUU
