DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual

4-56

 CAN Wiring

CSGCAN+ CAN-

Master

Slave

Shielded cable

CAN + C AN- CAN+ CAN-

Pin10

Pin8

Pin10

Pin8

CSGCSG Pin10Pin8

1. It is recommended to use Daisy Chain for connection and be sure to use terminal resistor in the

beginning and the end of the terminal arrangement.

2. Pin4 and Pin5 must be short-circuited to activate the built-in terminal resistor 120Ω.

DELTA_IA-PLC_DVP-ES3-EX3-SV3-SX31
