Delta DVP-ES3 Series Hardware Manual

DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
1-4
_1
Classification Model Name Description
DVP80ES300T
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 1x Ethernet port, 2x RS-485
ports, 1x USB & CAN port, 1x Micro SD interface, supporting 80
I/Os (40 DI + 40 DO) and up to 256 I/Os. Program capacity: 64K
steps, removable terminal blocks
DVP80ES300R
100-240 VAC powered CPU module
Relay output, 1x Ethernet port, 2x RS-485 ports, 1x USB & CAN
port, 1x Micro SD interface, supporting 80 I/Os (40 DI + 40 DO)
and up to 256 I/Os. Program capacity: 64K steps, removable
terminal blocks
DVP-ES3
EtherCAT
communication
CPU module
DVP32ES300TEC
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 1x Ethernet / EtherCAT port, 2x
RS-485 ports, 1x USB port, 1x Micro SD interface, supporting 32
I/Os (16 DI +16 DO) and up to 256 I/Os. Program capacity: 64K
steps, removable terminal blocks;
Supported EtherCAT Master 8 axes point to point positioning
control (for Delta drives only)
DVP-EX3
Series CPU
module
DVP22EX300T
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 2x Ethernet ports (can act as a
switch), 2x RS-485 ports, 1x USB & CAN port, 1x Micro SD
interface, supporting 22 I/Os (12 DI + 8 DO + 2 AI) and up to 256
I/Os. Program capacity: 64K steps, removable terminal blocks
DVP22EX300R
100-240 VAC powered CPU module
Relay output, 2x Ethernet ports (can act as a switch), 2x RS-485
ports, 1x USB & CAN port, 1x Micro SD interface, supporting 22
I/Os (12 DI + 8 DO + 2 AI) and up to 256 I/Os. Program capacity:
64K steps, removable terminal blocks
DVP36EX300T
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 2x Ethernet ports (can act as a
switch), 2x RS-485 ports, 1x USB & CAN port, 1x Micro SD
interface, supporting 36 I/Os (16 DI + 16 DO + 2 AI + 2 AO) and up
to 256 I/Os. Program capacity: 64K steps, removable terminal
blocks

Delta DVP-ES3 Series Specifications

General

Brand	Delta
Model	DVP-ES3 Series
Category	Controller
Language	English
