Delta DVP-ES3 Series Hardware Manual

Chapter 1 Product Introduction
1-5
1_
Classification Model Name Description
DVP36EX300R
100-240 VAC powered CPU module
Relay output, 2x Ethernet ports (can act as a switch), 2x RS-485
ports, 1x USB & CAN port, 1x Micro SD interface, supporting 36
I/Os (16 DI + 16 DO + 2 AI + 2 AO) and up to 256 I/Os. Program
capacity: 64K steps, removable terminal blocks
DVP28EX300MT
100-240 VAC powered CPU module
Transistor, NPN output (sinking), 2x Ethernet ports (can act as a
switch), 2x RS-485 ports, 1x USB & CAN port, 1x Micro SD
interface, supporting 28 I/Os (4 Diff. DI + 8 DI + 4 Diff. DO + 2 AI +
2 AO) and up to 256 I/Os. Program capacity: 64K steps, removable
terminal blocks
Digital
input/output
module
DVP08XM211N 8 inputs; 24 VDC; 5 mA
DVP08XP211R
4 inputs; 24 VDC; 5 mA
4 Relay outputs; 250 VAC; Below 30 VDC
2A/input, 5A/COM
DVP08XP211T
4 inputs; 24 VDC; 5 mA
4 NPN (sinking) outputs; 5 – 30 VDC;
0.5A/input, 4A/COM
DVP08XN211R
8 Relay outputs; 250 VAC; Below 30 VDC
2A/output, 5A/COM
DVP08XN211T
8 NPN (sinking) outputs; 5 – 30 VDC
0.5A/output, 4A/COM
DVP16XM211N 16 inputs; 24 VDC; 5 mA
DVP16XP211R
8 inputs; 24 VDC; 5 mA
8 Relay outputs; 250 VAC; Below 30 VDC
2A/input, 5A/COM
DVP16XP211T
8 inputs; 24 VDC; 5 mA
8 NPN (sinking) outputs; 5 – 30 VDC
0.5A/input, 4A/COM
DVP16XN211R
16 Relay outputs; 250 VAC; Below 30 VDC
2A/output, 5A/COM
