Delta DVP-ES3 Series Hardware Manual

Chapter 1 Product Introduction
1-9
1_
DVP20SX311R
24 VDC powered CPU module
Relay output, 1x Ethernet port, 2x RS-485 ports, 1x USB &
CAN port, 1x Micro SD interface, supporting 20 I/Os (8 DI +
6 DO + 4 AI + 2 AO) and up to 248 inputs and 246 outputs.
Program capacity: 64K steps, removable terminal blocks
DVP20SX311S
24 VDC powered CPU module
PNP output, 1x Ethernet port, 2x RS-485 ports, 1x USB &
CAN port, 1x Micro SD interface, supporting 20 I/Os (8 DI +
6 DO + 4 AI + 2 AO) and up to 248 inputs and 246 outputs.
Program capacity: 64K steps, removable terminal blocks
Digital I/O
module
DVP06SN11R
6 Relay outputs; 250 VAC; Below 30 VDC
6A/output
DVP08SN11R
8 Relay outputs; 250 VAC; Below 30 VDC
1.5A/output, 5A/COM
DVP08SN11T
Transistor, 8 NPN outputs (sinking), 30 VDC;
55°C, 0.1A/output; 50°C, 0.15A/output; 45°C, 0.2A/output;
40°C, 0.3A/output; 2A/COM
DVP16SN11T
Transistor, 16 NPN outputs (sinking), 30 VDC;
55°C, 0.1A/output; 50°C, 0.15A/output; 45°C, 0.2A/output;
40°C, 0.3A/output; 2A/COM
DVP08SP11R
4 inputs; 24 VDC; 5 mA
4 Relay outputs; 250 VAC; Below 30 VDC;
1.5A/output, 5A/COM
DVP08SP11T
4 inputs; 24 VDC; 5 mA
4 transistor outputs, 30 VDC; 55°C 0.1A/output; 50°C
0.15A/output; 45°C, 0.2A/output;
40°C, 0.3A/output, 2A/COM
DVP08SM11N 8 inputs; 24 VDC; 5 mA
DVP08SM10N 8 inputs; 85-132 VAC (50~60Hz) ; 9.2 mA (10VAC/60Hz)
DVP08SN11TS
8 transistor outputs (sourcing); 30 VDC;
55°C, 0.3A/output, 2A/COM
DVP08ST11N 8 inputs (dip switch)
