DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
1-10
_1
DVP16SP11R
8 inputs; 24 VDC; 5 mA
8 Relay outputs; 250 VAC; Below 30 VDC;
1.5A/output, 5A/COM
DVP08SP11TS
4 inputs; 24 VDC; 5 mA
4 transistor outputs (sourcing), 30 VDC;
55°C 0.3A/output, 2A/COM
DVP16SP11T
8 inputs; 24 VDC; 5 mA
8 transistor outputs (sinking), 30 VDC; 55°C 0.1A/output;
50°C, 0.15A/output; 45°C, 0.2A/output; 40°C, 0.3A/output,
2A/COM
DVP16SP11TS
8 inputs; 24 VDC; 5 mA
8 transistor outputs (sourcing); 30 VDC; 55°C, 0.3A/output,
2A/COM
DVP16SN11TS
16 transistor outputs (sourcing); 30 VDC; 55°C,
0.3A/output, 2A/COM
DVP16SM11N 16 inputs; 24 VDC; 5 mA
DVP32SN11TN 32 inputs; 24 VDC; 5 mA
DVP32SM11N
32 transistor outputs (sinking); 5-30 VDC; 0.1A/output;
55°C, 1.0A/COM; 25°C, 2.2A/COM
Analog I/O
module
DVP04AD-S2
4 channel analog inputs (differential)
14-bit resolution: -10 to 10 V, -6 to 10 V
13-bit resolution: -20 to 20 mA, -12 to 20 mA
Conversion time: 3ms/channel
DVP04DA-S2
4 channel analog outputs
12-bit resolution: 0 to 10 V, 2 to 10 V, 0 to 20 mA, 4 to 20 mA
Conversion time: 3ms/channel
DVP06XA-S2
4 channel analog inputs (differential)
12-bit resolution: -10 to 10 V, -6 to 10 V
11-bit resolution: -20 to 20 mA, -12 to 20 mA
Conversion time: 3ms/channel
2 channel analog outputs
12-bit resolution: 0 to 10 V, 2 to 10 V, 0 to 20 mA, 4 to 20 mA
Conversion time: 3ms/channel
