DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
8-30
_8
 Select
RTU1 Enable
to enable this RTU function. You can set each RTU individually.
 Set a station address and an IP address.
 Set the RX mapping address and RX mapping length to make the digital input points for the DI module
connected to RTU and mapped to X/M devices, as well as the length for the DVP-ES3 Series module. Set the
RY mapping address and length to set the digital output points for the DO module mapped to Y/M devices, as
well as the length for the DVP-ES3 Series module.
 Set the RCR Read mapping address and RCR Read mapping length to make the analog input points for the AI
module connected to RTU and mapped to D/SR devices, as well as the length for the DVP-ES3 Series module.
Use the RCR Write mapping address and length to set the analog output points for the AO module mapped to
D/SR devices, as well as the length for the DVP-ES3 Series module.
