Appendix C: Assembly Note

-All Model

NO Location Screw torque

2 Screw assemblies 7 lbf-in (0.8N.m)

3 Fan 7 lbf-in (0.8N.m)

1 Filter 7 lbf-in (0.8N.m)

Appendix C-1: Assembly Note for All model

①

③

107

Appendix C: Assembly Note
