Symbol Definition
FCC designation
Please read the user manual for further information
Danger: Electrical Hazard
This icon indicates that a prescribed time delay must elapse
before engaging in an indicated action.Electrical hazard might
exist before this duration.
Warning of the hot surface of the inverter
Table 2-2: Rating label explanation of M42/36/28U
In the following pages, Figures 2-4 through 2-6 illustrate the general layout
of the M42/36/28U chassis and wiring box, and Figure 2-7 and Table 2-3,
provides a detailed description of each wiring box option.
The Wiring Box area includes terminals for connection of the inverter input (DC)
wiring, output (AC) wiring, RS-485 communication and other signal wiring, as
well as DC & AC surge protection devices (SPD), DC switches, and fuse holders
for some models.
Use noise protection PPE
ETL Listed Mark approved by Intertek Lab
Certified as Grid Support Utility Interactive Inverter
