Figure 3-22: Multiinverter connection illustration

Data Format:

Baud rate: 19200

Data bits: 8

Stop bit: 1

Parity: N/A

RS485/USB

RS485/RS232

Terminal Resistor

(Last inverter in chain must have

Switch 2 in ON position.)

Switch 1

Terminal Resistor ON

Terminal Resistor OFF

OFF

Table 3-2: Terminal resister setting
