Delta M42U

To Next Page

To Previous Page

122

M42U

M36U

M28U

Figure 2-6: External view and Wiring box layout for 122 models

Dual MPPT channels, 6 strings/input

Dual MPPT channels, 5 strings/input

Dual MPPT channels, 4 strings/input
