Delta M42U

To Next Page

To Previous Page

Figure 3-2: Mounting bracket dimensions

796.4 mm [31.4 in]

739.4 mm [29.1 in]

611.9 mm [24.1 in]

50 mm [2.0 in]

246 mm [9.7 in]

410 mm [16.1 in]

205 mm [8.1 in]

400 mm [15.7 in]

Necessary for vertical mounting Necessary for horizontal mounting

Figure 3-3: Required position for at least 8 screws

Installation
