The components of M42U/M36U/M28U is shown as Figure 2-1.
2.2 Product Overview
① ③② ④
Table 2-1: Packing list of M42U/M36U/M28U series
Figure 2-1: Components of M42U/M36U/M28U series
3 pcs
9
Screw
Ground bar mounting screws (122 Models)
(Stainless/M5/21mm)
5 pcs
10
Screw
To secure inverter to mounting bracket
(Stainless/M6/12mm)
Object Qty Description
1 Delta Solar Inverter 1 pc
1 pc
1 pc
Solar inverter
2 Wiring Gland 1 pc For communication port wiring
6 Shielding plate 1 pair Shelding plate for filter (use is optional)
5 Name plate cover 1 set Name plate cover for display
3 User Manual
Important instructions for solar inverter
Safety instructions should be followed
during installation and maintenance
4 Mounting Bracket
Wall mounting bracket
(Material: Aluminum/Thickness: 3mm)
7
Al Alloy Busbar 1 pc DC side PE/EGC Ground bar (122 Models)
8 MC4 connector
12 pairs String inputs for M42U
_122 model
10 pairs String inputs for M36U
_122 model
8 pairs String inputs for M28U_122 model
⑦⑥
⑨⑧ ⑩
For 122 model
⑤
BACK SIDE
