Delta M42U - Figure 2-4: External View and Wiring Box Layout for 120 Models

Dual MPPT channels, 6 strings/input
Dual MPPT channel, 5 strings/input
Dual MPPT channel, 4 strings/input
120
M42U
M36U
M28U
Figure 2-4: External view and Wiring box layout for 120 models
19
Introduction
