Figure 3-1: Inverter dimensions

615 mm [24.2 in]

818 mm [32.2 in]864 mm [34 in]

275 mm [10.8 in]

615 mm [24.2 in] 275 mm [10.8 in]

120 & 121

Models

122

Models

Installation
