Figure 7-1: Thermal Derating curve of M42U

30

25

35

40 45 50

55

60

50 %

55 %

60 %

65 %

70 %

75 %

80 %

85 %

90 %

95 %

100 %

105 %

110 %

115 %

P/P*

P*=42kW

545V

710V

830V

Temperature Derating of M42U

97

Technical Data
