Delta M42U

To Next Page

To Previous Page

Remove name plate cover

If there is needed to monitoring or setting the display, please follow procedure below.

CAUTION !

②

①

① Separate the large plate.

② Pull out the large plate.

Loose two screws.

Start monitoring or using the

display.
