Delta VFD-B User Manual

Chapter 5 Parameters|VFD-B Series
5-48 Revision July 2008, BE16, SW V4.08 & V5.00
Group 4: Input Function Parameters
04 - 00 AVI Analog Input Bias
Unit: 0.01
Settings 0.00 to 200.00% Factory Setting: 0.00
04 - 01 AVI Bias Polarity
Factory Setting: 00
Settings 00 Positive Bias
01 Negative Bias
04 - 02 AVI Input Gain
Unit: 1
Settings 1 to 200% Factory Setting: 100
04 - 03 AVI Negative Bias, Reverse Motion Enable/Disable
Factory Setting: 00
Settings 00 No AVI Negative Bias Command
01 Negative Bias: REV Motion Enabled
02 Negative Bias: REV Motion Disabled
04 - 11 ACI Analog Input Bias
Unit: 0.01
Settings 0.00 to 200.00% Factory Setting: 0.00
04 - 12
ACI Bias Polarity
Factory Setting: 00
Settings 00 Positive Bias
01 Negative Bias
04 - 13 ACI Input Gain
Unit: 1
Settings 01 to 200% Factory Setting: 100
04 - 14 ACI Negative Bias, Reverse Motion Enable/Disable
Factory Setting: 00
Settings 00 No ACI Negative Bias Command
01 Negative Bias: REV Motion Enabled
02 Negative Bias: REV Motion Disabled
04 - 15 AUI Analog Input Bias
Unit: 0.01
Settings 0.00 to 200.00% Factory Setting: 0.00
04 - 16 AUI Bias Polarity
Factory Setting: 00
Settings 00 Positive Bias
01 Negative Bias
04 - 17 AUI Input Gain
Unit: 1
Settings 01 to 200% Factory Setting: 100

Delta VFD-B Specifications

General

Series	VFD-B
Power Range	0.4kW to 15kW
Control Method	V/F Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Communication	RS-485
Protection Features	Over-voltage, Over-current, Overheat, Under-voltage, Ground fault, Short circuit
