Delta VFD-B User Manual

Chapter 5 Parameters|VFD-B Series
Revision July 2008, BE16, SW V4.08 & V5.00 5-57
ON ON ON ON ON ON ON ON
ONONONON
ON
ON
ON
ON
05-00
05-01
05-02
05-03
05-04
05-05
05-06
05-07
05-08
05-09
05-10
05-11
05-12
05-13
05-14
01-14
OFF
OFF
OFF
OFF
OFF
123456789101112131415
M
u
l
t
i
-
f
u
n
c
t
i
o
n
t
e
r
m
in
a
ls
M
I
1
~
M
I
6
0
4
-
0
4
~
0
4
-
0
9
Frequency
Master Speed
JOG Freq.
2nd speed
(MI1 to MI6 2)
1st speed
(MI1 to MI6 1)
Jog Freq.
Multi-speed via External Terminals
Run/Stop
PU/external terminals
/communication
3rd speed
(MI1 to MI6 3)
4th speed
(MI1 to MI6 4)
MI4=4 MI3=3 MI2=2 MI1=1
Master frequency OFF OFF OFF OFF
1
st
speed OFF OFF OFF ON
2
nd
speed OFF OFF ON OFF
3
rd
speed OFF OFF ON ON
4
th
speed OFF ON OFF OFF
5
th
speed OFF ON OFF ON
6
th
speed OFF ON ON OFF
7
th
speed OFF ON ON ON
8
th
speed ON OFF OFF OFF
9
th
speed ON OFF OFF ON
10
th
speed ON OFF ON OFF
11
th
speed ON OFF ON ON
12
th
speed ON ON OFF OFF
13
th
speed ON ON OFF ON
14
th
speed ON ON ON OFF
15
th
speed ON ON ON ON
04 - 10 Digital Terminal Input Debouncing Time Unit: 2
Settings
1 to 20
Factory Setting: 1

Delta VFD-B Specifications

General

Series	VFD-B
Power Range	0.4kW to 15kW
Control Method	V/F Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Communication	RS-485
Protection Features	Over-voltage, Over-current, Overheat, Under-voltage, Ground fault, Short circuit
