Delta VFD-B User Manual

Chapter 2 Installation and Wiring|VFD-B Series
2-8 Revision July 2008, BE16, SW V4.08 & V5.00
Frame D: VFD150B23A/43A/53A, VFD185B23A/43A/53A, VFD220B23A/43A/53A
13.0 [0.51]
10.0 [0.39]
R5
.
0
[
R
0
.
2
0
]
403.8 [15.90]
384.0 [15.12]
4
2
.
0
[
1
.
6
5
]
(
2
X
)
250.0 [9.84]
226.0 [8.90]
2
8
.
0
[
1
.
1
0
]
205.4 [8.08]
10.0 [ 0.39]

Delta VFD-B Specifications

General

Series	VFD-B
Power Range	0.4kW to 15kW
Control Method	V/F Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Communication	RS-485
Protection Features	Over-voltage, Over-current, Overheat, Under-voltage, Ground fault, Short circuit
