GAVIN-8C Instruction Manual
- 8 -
Switch
SA: 3 positions, alternate, short lever
SB: 3 positions, alternate, short lever
SC: 2 positions, momentary, short lever
SD: 3 positions, alternate, short lever
SE: 3 positions, alternate, short lever
SF: 2 positions, alternate, short lever
Users can assign the above switches to specified functions (for example,
throttle hold, acrobatic flight, etc.) according to individual habits. For details,
please refer to Function Set (Page 43).
Sticks: When the Stick Mode is set to MODE 1, the positions of sticks are
shown in the figure.
Digital Trims: This transmitter is equipped with four digital trims. Each time
you press a trim button, the trim position moves one step. If you press and
hold it, the output will scroll in that direction until the trim button is released or
the output reaches its ends. You can always monitor trim positions by
referencing the LCD screen.
CAUTION: The trim positions you have set will be stored in memory and will
remain there even the transmitter powered off.
Keys
EXT: exit key, press this key to return to the previous menu.
UP: press this key to select the menu upward.
DOWN: press this key to select the menu downward.
ENT: enter key, press this key to enter the sub-menu or to confirm the
setting.
R/+: press this key to choose the value upward.
L/-: press this key to choose the value downward.
LCD: You can get the current status from the main screen, and set the
parameters from the menu.
Simulator/Trainer Connector
