Dexter Laundry A Series Service Procedures And Parts Data

Key Description T-300 T-400 T-600 T-900 T-1200 QTY
12 Screw GRN. #10-32x 1/2” 8639-621-007 8639-621-007 8639-621-007 8639-621-007 8639-621-007 1
13 Lockwasher #10 8641-582-006 8641-582-006 8641-582-006 8641-582-006 8641-582-006 1
14 Lug, Grounding 8652-130-037 8652-130-037 8652-130-037 8652-130-037 8652-130-037 1
15 PCB assembly Relay Main 9473-006-001 9473-006-001 9473-006-001 9473-006-001 9473-006-001 1
16 Spacer Plastic #8x3/8” 9538-157-011 9538-157-011 9538-157-011 9538-157-011 9538-157-011 6
17 Nuts Hexkeps #6-32 8640-411-003 8640-411-003 8640-411-003 8640-411-003 8640-411-003 6
18 Harness Drain/Therm/Sol 9627-796-001 9627-796-001 9627-796-002 9627-796-002 9627-796-002 1
19 Harness P19/Water Valve 9627-795-001 9627-795-001 9627-795-002 9627-795-002 9627-795-002 1
20 Harness P8/P16 9627-794-001 9627-794-001 9627-794-001 9627-794-001 9627-794-001 1
21 Harness P20/P21 9627-793-001 9627-793-001 9627-793-001 9627-793-001 9627-793-001 1
23 Bushing , Wire 7/8 9053-067-002 9053-067-002 9053-067-002 9053-067-002 9053-067-002 2
24 Standoff Twistlock 9527-002-002 9527-002-002 9527-002-002 9527-002-002 9527-002-002 3
25 Standoff Twistlock 9527-002-003 9527-002-003 9527-002-003 9527-002-003 9527-002-003 2
26 Dynamic Braking Resistor 9483-004-002 9483-004-002 9483-004-002 9483-004-003 9483-004-003 2
27 Screws #10-32x1/2” (pnhdcr) 9545-012-008 9545-012-008 9545-012-008 9545-012-008 9545-012-008 4
28 Nuts, #10-32 UNF 2B 8640-413-002 8640-413-002 8640-413-002 8640-413-002 8640-413-002 4
30 Screw #6-32x5/16” 9545-044-006 9545-044-006 9545-044-006 9545-044-006 9545-044-006 4
31 Nuts Hex #6-32 8640-411-003 8640-411-003 8640-411-003 8640-411-003 8640-411-003 4
32 Terminal Block Assy, POWER Rear 9897-034-001 9897-034-001 9897-034-001 9897-034-001 9897-034-001 1
33 Screw, Mtg 8Bx3/8” 9545-045-007 9545-045-007 9545-045-007 9545-045-007 9545-045-007 2
34 Strip, Terminal Marker 9558-027-001 9558-027-001 9558-027-001 9558-027-001 9558-027-001 1
35 Switch, Pressure 9539-491-001 9539-489-001 9539-489-001 9539-489-001 9539-488-001 1
36 Screw, Mtg #8Bx1/4” 9545-045-001 9545-045-001 9545-045-001 9545-008-026 9545-008-026 2
37 Harness P5/Pressure 9627-800-001 9627-805-001 9627-806-001 9627-803-001 9627-803-001 1
38 Transformer, (Step Down) 8711-009-001 8711-009-001 8711-009-001 8711-009-001 8711-009-001 1
120/2.3 VAC&24 VAC 50/60hz
39 Screw, Transformer Mtg #10Bx1/2” 9545-045-001 9545-045-001 9545-045-001 9545-045-001 9545-045-001 4
40 Lockwasher #10 exttooth 8641-582-005 8641-582-005 8641-582-005 8641-582-005 8641-582-005 4
47 Variable Frequency Drive (120 v) 9375-004-007 1
47 Variable Frequency Drive (208-240 v) 9375-005-007 9375-007-008 9375-007-010 9375-014-010 9375-018-002 1
48 Label Fuse 1.5 amp Rear 8502-716-001 8502-716-001 8502-716-001 8502-716-001 1
48 Label Fuse 2.5 amp Rear 8502-716-002 1
48 Terminal Block Assembly 9897-035-001 9897-033-002 1
-- Screw 8B x 1/2 9545-045-002 9545-031-010 2
-- Wiring Harness Power Terminal to VFD 9627-831-001 9627-747-003 9627-747-003 1
51 Wiring Harness Power Terminal 9627-747-002 9627-747-002 1
49 Plastic Shield Over Water Valve 9550-186-001 9550-186-001 9550-186-001 9550-186-001 1
50 PCB Assembly Relay Optional 9473-008-001 9473-008-001 9473-008-001 9473-008-001 9473-008-001 1
-- Screws 8 B x 1/4 9545-045-001 9545-045-001 9545-045-001 9545-045-001 9545-045-001 1
-- Screws # 10 B x 1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 9545-008-026 1
Parts Data
104
Electrical Components - Top Compartment
