DGH TECHNOLOGY SCANMATE FLEX - Symbol Definitions

5
GENERAL WARNING SIGN [2] REF NO. W001
Indicates the need for the user to consult the instrucons for use for important cauonary
informaon such as warnings and precauons that cannot be presented on the medical device
itself.
TYPE B APPLIED PART [3] REF NO. 5840
This symbol indicates the degree of protecon against electric shock. The Scanmate Flex is
classied as Type B Applied Part. This symbol is located on the unit label.
CLASS II EQUIPMENT [3] REF NO. 5172
This symbol indicates that the device is an IEC Protecon Class II (double insulated) device.
CONSULT INSTRUCTIONS FOR USE [1] REF NO. 1641
Indicates the need for the user to consult the instrucons for use.
CATALOGUE NUMBER [1] REF NO. 2493
Indicates the manufacturer's catalogue number so that the medical device can be idened.
SERIAL NUMBER [1] REF NO. 2498
Indicates the manufacturer's serial number so that a specic medical device can be idened.
MANUFACTURER [1] REF NO. 3082
Idenes the device manufacturer. Adjacent to the symbol is the name and address of the
manufacturer.
ATMOSPHERIC PRESSURE LIMITATION [1] REF NO. 2621
Indicates the range of atmospheric pressure to which the medical device can be safely exposed.
HUMIDITY LIMITATION [1] REF NO. 2620
Indicates the range of humidity to which the medical device can be safely exposed.
TEMPERATURE LIMIT [1] REF NO. 0632
Indicates the temperature limits to which the medical device can be safely exposed.
ON (POWER) [3] REF NO 5007
Indicates power on posion for the switch.
OFF (POWER) [1] REF NO 5008
Indicates the power o posion for the switch.
STANDBY [3] REF NO 5009
Indicates the standby status of the device (device powered on).
BATTERY CHECK INDICATOR
Indicates the buon pressed to check the baery charge status of the device.
BATTERY CHARGE INDICATOR
Indicates the amount of baery charge remaining
ACTIVE CHARGING INDICATOR
Indicates that the device is charging the baery.
[1] EN ISO 7000 (5th Ed) Graphical Symbols For Use On Equipment
[2] EN ISO 7010 (2nd Ed) Graphical Symbols—Safety Color and Safety Signs—Registered Safety Signs
[3] IEC 60417:2002 DB Graphical Symbols For Use On Equipment
[4] ISO 15223-1:2012 Medical Devices—Symbols To be Used With Medical Devices Labels, Labeling, And Informaon To Be
Supplied—Part 1: General Requirements
!
SYMBOL DEFINITIONS
