ELECTROMAGNETIC IMMUNITY AND EMISSIONS
The Electro Magnec Interference and Compability tesng of the Scanmate Flex was
performed to determine compliance with emissions and immunity requirements set forth by the
European Community under the requirements of the EMC Direcve (2004/108/EC). The system
complied with the radiated emissions requirements throughout the test.
GUIDANCE AND MANUFACTURER’S DECLARATION
ELECTROMAGNETIC IMMUNITY
The Scanmate Flex is intended for use in the electromagnec environment specied below. The customer
or the user of the Scanmate Flex should assure that it is used in such an environment.
Immunity Test
Basic Standard
IEC 60601
Test Level
Compliance
Level
Electromagnec
environment - guidance
Electrostac
Discharge (ESD)
Immunity
IEC 61000-4-2
Indirect Applicaons
±2 kV, ±4 kV, ±6kV, ±8kV Contact
Direct Applicaons
±2 kV, ±4 kV, ±6kV, ±8kV Contact
±2 kV, ±4 kV, ±6kV, ±8kV, ±15kV Air
Complies
Floors should be wood,
concrete, or ceramic le. If
oors are covered with
synthec material, the
relave humidity should be
at least 30%
Electric Fast
Transient / Burst
Immunity
IEC 61000-4-4
2 kV for AC Mains
1 kV for signal I/O lines
Complies Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge Immunity
IEC 61000-4-5
±0.5, ±1 kV, ±2 kV line(s) to line(s)
±0.5kV, ±1 kV for AC Mains
Complies Mains power quality should
be that of a typical
commercial or hospital
environment.
Voltage Dips and
Interrupons
IEC 61000-4-11
0% U
T
(100% reducon from U
T
)
for 0.5 cycle
40% U
T
(60% reducon from U
T
)
for 6 cycles
70% U
T
(30% reducon from U
T
)
for 30 cycles
5% U
T
(95% reducon from U
T
)
for 300 cycles @ 100V/60Hz
For 250 cycles @230V/50Hz
Complies
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
the Scanmate Flex requires
connued operaon during
power mains interrupons,
it is recommended that the
Scanmate Flex be powered
from an uninterrupble
power supply or baery.
Power Frequency
Magnec Field
Immunity
IEC 61000-4-8
30 A/m at 50 Hz
30 A/m at 60Hz
Complies
Power frequency magnec
elds should be at levels
characterisc of a typical
locaon in a typical
commercial or hospital
environment.
NOTE U
T
is the AC mains voltage prior to applicaon of the test level.
