REVIEWING B-SCAN AND UBM VIDEOS
ADJUSTING SCAN IMAGES
The Gain, Intensity, Contrast and Zoom controls (available on the right-hand side of the screen)
can be used to enhance the quality of the image. These sengs can be adjusted before, during
or aer a procedure.
ADDING ANNOTATIONS
Once complete, the exam can be annotated with comments and measurements using the
provided tools. To enable measurement tools and show measurement notaons, click on the
[MEASUREMENT TOOLS CHECKBOX]. To disable measurement tools and hide notaons, clear
the [MEASUREMENT TOOLS CHECKBOX].
Distance Measurement: To perform a distance measurement, le-click on the
[CALIPER TOOL] then hold the le mouse buon and drag
across the distance to be measured. A line will appear
indicang the measured distance and a measurement value will
appear on at the end of the line. Mulple measurements may be
performed, however the [CALIPER TOOL] must be selected before
each measurement. Measurements can be deleted by right-clicking
on a measurement line and selecng “Delete” from the drop down
menu.
Angle Measurement: Click the [ANGLE TOOL], Use single clicks of the right mouse
buon to designate three points to create the desired angle.
Area Calculaon: Click the [AREA TOOL]. Use single-clicks of the le mouse
buon to designate points around the desired area. Once all
points have been designated, single-click the right mouse to
perform the calculaon.
Ruler Overlay: A ruler overlay will be displayed when the [RULER] buon is
clicked. It will be hidden when the buon is clicked again.
The ruler overlay can also be controlled via voice commands.
DELETING NOTATIONS
Distance, angle and area notaons can be removed by right-clicking on the lines and selecng
“Delete” from the menu displayed or by le-clicking on the line to select it and pressing the
“Delete” keyboard key
CREATING B-SCAN/UBM REPORTS
Click the [REPORT] buon in the upper right-hand corner of the screen. Select the check box of
the desired images. Images are inserted into the report in the order selected. The report can be
saved to the database as a PDF or printed.
Reports that had been saved to the database will be displayed in the window with paent scans.
PDF versions of reports can be exported by le-clicking and dragging the thumbnail image to the
desired locaon. Refer to the Exporng and Imporng Data secon for more informaon.
