Page 15 of 87 DGH 55B-INS-OMENG Rev: 3
7 ENT Key
In measurement mode, pressing key will display battery status. In configuration mode, the key is
used to advance to the next configurable parameter. Pressing and holding this key will send
measurements to a PC/Printer (only available with Bluetooth
®
option installed).
8 OS Key
Press key to review or take measurements of the LEFT eye.
9 / Keys
Used to review measurements or to program options and numerical values presented on the
display.
10 OD Key
Press key to review or take measurements of the RIGHT eye. Also used while in the
configuration menu to confirm some device parameters.
11 PWR Key
Pressing this key turns the Pachmate 2 on. When the Pachmate 2 is on, pressing and holding
this key turns the Pachmate 2 off. Also used in conjunction with the DEL key to enter the
CalBox mode.
12 Lanyard Loop
Allows a point of attachment for a lanyard.
