Page 20 of 87 DGH 55B-INS-OMENG Rev: 3
7.1.2 When inserting the probe, align
the probe connector prong to fit
into the Pachmate 2. The prong
is a half-circle with a small hole
in it.
7.1.3 The connectors are designed to go together
WITHOUT twisting. When inserting or removing
the probe, slide the connectors together without
twisting.
7.2 Holding the Device
While handling the device, try to avoid contact with the probe tip (clear plastic cone) so as to
avoid contamination. Touching the probe tip with ungloved hands may leave a residue that will
cause the device to return an error message when self-testing (See section 7.3).
