Page 37 of 87 DGH 55B-INS-OMENG Rev: 3
12.1.6 The Pachmate 2 is now ready to take corneal measurements. If any default parameters
need to be modified, refer to section 13. Otherwise, refer to sections 12.2 and 12.3 for
detailed descriptions of the proper methods for obtaining measurements.
12.2 Measurement in Continuous Averaging Mode
NOTE: Typically, anesthetizing the patient’s eye is necessary for obtaining a measurement.
12.2.1 Perform the Power Up Sequence as described in Section 12.1.
12.2.2 Press the CFG key to enter the Configuration Menu. Press the ENT key repeatedly to
navigate through the menu.
12.2.3 Confirm that Continuous Averaging Mode is selected in the ‘Operational Mode’ menu.
(See Section 11.3)
12.2.4 Select a memory location to associate measurements with, or select Single Patient Mode.
(See Sections 10.1 and 10.2)
12.2.5 Select the number of measurements to be obtained (default is 25 measurements).
(See Section 13.2.2)
12.2.6 Press the CFG key to exit the Configuration Menu.
If changes have been made, the Pachmate 2 will
prompt for confirmation of the configuration
change.
12.2.7 Press the key to select ‘Yes’ and save the configuration. The Pachmate 2 will return
to Measurement Mode.
12.2.8 Select the eye to be measured. You can select either
eye for measurement by pressing the OD or OS
key. The selected eye will be displayed in the upper
left-hand corner. By default, the device is prepared
to measure the RIGHT eye.
12.2.9 Have the patient visualize a fixation point.
