Page 35 of 87 DGH 55B-INS-OMENG Rev: 3
11.3 Changing Measurement Modes
WARNING: All measurements in the device, including those stored in memory will be
cleared when the Measurement Mode is changed. Check that all required data has been
recorded outside of the device before changing the Measurement Mode.
11.3.1 Upon power-up the Pachmate 2’s Measurement Mode will be set to the last setting used
(factory default is Continuous Averaging).
11.3.2 To check the Measurement Mode setting, press the
CFG key, and then repeatedly press the ENT key to
scroll through the configuration options. Scroll until
the ‘Operational Mode’ menu is displayed.
11.3.3 Pressing the or key will switch between
Continuous Averaging or Mapping modes.
11.3.4 Press the CFG key when the preferred mode is
displayed. If changes have been made, the device
will display the ‘Save New Config’ message.
11.3.5 Press the key to select ‘Yes’ to save the configuration.
• If there is data that is cleared, the device will
display the ‘ALL MEAS CLEARED
Config Saved’ message.
• If there is no data to clear, the device will
display the ‘Saving New Config’ message.
• After the message is displayed, the device will show the screen for the appropriate
Measurement Mode.
