Page 44 of 87 DGH 55B-INS-OMENG Rev: 3
13. Configuring the Pachmate 2
When shipped from the factory, the Pachmate 2 is ready to take corneal measurements. No
additional setup or configuration is necessary. However, the Pachmate 2 has been designed to
allow the operator to modify certain parameters to tailor the instrument to meet one’s needs.
Once modified, these parameters are permanently stored in non-volatile memory and are
automatically recalled each time the unit is powered up. To change a parameter, the operator
must access the configuration menu. The following procedure explains how to access the
configuration menu and modify the default parameters.
13.1 Entering and Navigating the Configuration Menu
13.1.1 To enter the Configuration Menu, press the CFG
Key. The screen will display:
13.1.2 While in the Configuration Menu, each time that the ENT key is pressed the device will
display the next editable parameter. When the last parameter is reached and the ENT key
is pressed, the device will re-start the list.
13.1.3 To change a parameter setting, use the , , OD or OS keys as indicated in the table
below.
13.1.4 After all necessary changes have been made, press the CFG key again.
13.1.5 If changes have been made, the ‘Save New
Config?’ message will appear. Select ‘Yes’ or ‘No’
as appropriate.
