Page 40 of 87 DGH 55B-INS-OMENG Rev: 3
12.3 Measurement in Mapping Mode
NOTE: Typically, anesthetizing the patient’s eye is necessary for obtaining a measurement.
12.3.1 Perform the Power Up Sequence as described in Section 12.1.
12.3.2 Press the CFG key to enter the Configuration Menu. Press the ENT key repeatedly to
navigate through the menu.
12.3.3 Confirm that Mapping Mode is selected in the ‘Operational Mode’ menu.
(See Section 11.3)
12.3.4 Select a memory location to associate measurements with, or select Single Patient Mode.
(See Sections 10.1 and 10.2)
12.3.5 Select the number of positions to be measured (default is 33 measurements).
(See Section 13.3.1)
12.3.6 Press the CFG key to exit the Configuration Menu.
If changes have been made, the Pachmate 2 will
prompt for confirmation of the configuration change.
12.3.7 Press the key to select ‘Yes’ and save the configuration. The Pachmate 2 will return
to Measurement Mode.
