6.2 Back View
Exton PA USA
TECHNOLOGY, INC.
DGH 55B
Pachymeter
0120
!
1 2 3
Fig 6.2.1 The DGH 55B (Pachmate 2) Back View
1 Battery Compartment
A label in the battery compartment will show proper battery alignment. The unit model number
and serial number are also located on the label inside the battery compartment.
• The note “Contains Transmitter Module FCC ID: T7VEBMU / IC: 216QEBMU” will
appear on the battery compartment label in devices that contain a Bluetooth® wireless
module.
2 Model Number
Location of model number used to identify the unit.
3 Device Labels
Refer to Section 2 for descriptions of device classification and attention symbols.
