Page 72 of 87 DGH 55B-INS-OMENG Rev: 3
15.7 Initiating measurement transfer using the Pachmate 2
15.7.1 Check that the Pachmate 2 is placed in the correct Patient Mode:
• If in Single Patient Mode, only the single patient measurements will be retrieved by
the computer.
• If in Multi Patient Mode, all measurements in the patient memory locations will be
retrieved by the computer.
15.7.2 Check that the device is sending to a PC:
• If the device has already been pre-configured to send to a PC, press and hold the ENT
key. The Pachmate 2 will attempt to send measurements. (Go to 15.7.5)
• If you are unsure if the device is pre-configured, check that the Pachmate 2 is
sending the records to the proper device. To do this, press the CFG key to enter the
Configuration Menu and repeatedly press the ENT key to navigate to the ‘Send Meas
To’ menu.
15.7.3 Use the and keys to scroll through the saved
configurations.
o NAME is the name of the device that will
receive the records.
o #
A
is the list number of the device shown.
o #
B
is the total number of devices paired with the Pachmate 2. Up to 5 devices can
be paired at a time.
o Send → indicates that pressing the OD key will cause the Pachmate 2 to transmit
measurements to the currently displayed device.
15.7.4 With the desired device displayed, press the OD key to select ‘Send’.
