Page 42 of 87 DGH 55B-INS-OMENG Rev: 3
12.3.12 After each successful measurement the device will
show the result on the display for a short time
(Good Measurement Delay, default 2 seconds).
• During this time either wait for two short ‘beeps’ before re-applanating the probe at
the next mapping position or:
• Re-applanate at the same point to re-measure that mapping position.
12.3.13 The device will emit two short ‘beeps’ when it is ready to take the measurement at the
next mapping position. Reposition the probe and re-applanate at the next position to be
mapped.
12.3.14 Continue measuring all positions until all necessary measurements have been taken.
12.3.15 The device DOES NOT indicate when all
measurements have been taken; instead it will go
back to the measurement for position number 1.
• To scroll through each measurement press the
or key. The device will list the position
number and list the thickness measurement
below.
12.3.16 If a questionable measurement is found during review, the operator can delete it. To do
this, the operator presses the DEL key while viewing the measurement in question.
• The operator can take new measurements to replace those that were deleted or choose
to accept the remaining measurements.
12.3.17 If the device is operating in Multi-Patient Mode the measurements will be automatically
saved to memory.
