Description of the Machine 21
4.5 Electrical Installation
The electrical installation provides power for the vacuum pump, the seal system and the operation
of the machine.
See the electrical diagram for the further structure and operation of the electrical installation.
Please contact your supplier for the electrical diagram.
Only a technical expert may perform work on the electrical installation.
The machine consists of the following electrical components:
Figure 5: Overview of the Electrical Installation
1. Power connection and cable
This serves to connect the machine to the power supply.
2. Control panel
This serves to operate the control functions. Depending on your model, your machine will have
one of the following control options:
• Operating Elements of the 10-Program Control System on page 23
• Operating Elements of the Advanced Control System (ACS) on page 24
3. USB connector (only in case of ACS control)
The USB connector is located on the side or the rear of the machine. Reaching the USB
connector requires removing the rear wall.
The USB connector enables the import and export of data.
