11.2 Example Programs
Example programs of the 10-program control system
Prog Vacuum Vacuum+ Seal Soft-air Type of product
1. 99% OFF 2.2 s 3 s Solid products
2. 97% N/A 2.2 s OFF
Liquids/liquid-
containing products
3. 99% OFF 2.2 s 8 s Fragile/sharp products
4. 99% 4 s 2.2 s 3 s
Product that may
contain entrapped air
Set as sensor-controlled
Prog no. 1 2 3 4 5 6 7 8 9 10
Vacuum 99% 97% 99% 99% 80% 90% 50% 90% 60% 99%
Vacuum+ OFF OFF 4 s 15
Gas OFF OFF OFF 60% 50% 80% OFF 80% 30% OFF
Seal 2.2 s 2.2 s 2.2 s 2.2 s 2.5 s 2.5 s 2.5 s 2.5 s 2.5 s 2.5 s
Seal 2 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s
Soft-air 3 s OFF 8 s 3 s OFF OFF 2 s OFF OFF 3 s
Set as controlled by Liquid Control sensor
Prog no. 1 2 3 4 5 6 7 8 9 10
Vacuum 99% 97% 99% 99% H2O 90% 50% 90% 60% 99%
Vacuum+ OFF OFF 4 s 15
Gas OFF OFF OFF 60% 50% 80% OFF 80% 30% OFF
Seal 2.2 s 2.2 s 2.2 s 2.2 s 2.5 s 2.5 s 2.5 s 2.5 s 2.5 s 2.5 s
Seal 2 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s
Soft-air 3 s OFF 8 s 3 s OFF OFF 2 s OFF OFF 3 s
