11.1.2 Technical Data Lynx
Lynx 32 42
General
Ambient temperature during operation 5 to 30°C 5 to 30°C
Sound emission < 70 dB(A) < 70 dB(A)
Maximum daily production 5 hrs/day 5 hrs/day
Dimensions of the machine
Width 534 mm 534 mm
Length 400 mm 491 mm
Height 385 mm 396 mm
Weight 35 kg 46 kg
Maximum product height 103 mm 114 mm
Gas flush system (optional)
Dimensions connector 6 mm 6 mm
Gas supply 60-100 l/min 60-100 l/min
Maximum supply pressure 1 bar 1 bar
Electrical connection
Supply voltage * *
Connected load * *
Vacuum pump
Capacity 8 m
3
/h 16 m
3
/h
Oil 0.5 litre 0.5 litre
Type of mineral oil VM32 VM32
Ambient temperature mineral oil 5 to 30°C** 5 to 30°C**
Type of synthetic oil Foodmax Air 32 Foodmax Air 32
Ambient temperature synthetic oil -10 to 40°C** -10 to 40°C**
*See machine plate.
**For different temperatures, please contact your dealer.
