11.1.3 Technical Data Toucan
Toucan Regular Square
General
Ambient temperature during operation 5 to 30°C 5 to 30°C
Sound emission < 70 dB(A) < 70 dB(A)
Maximum daily production 5 hrs/day 5 hrs/day
Dimensions of the machine
Width 480 mm 480 mm
Length 581 mm 581 mm
Height 795 mm 795 mm
Weight 108 kg 108 kg
Maximum product height 275 mm 330 mm
Gas flush system (optional)
Dimensions connector 6 mm 6 mm
Gas supply 60-100 l/min 60-100 l/min
Maximum supply pressure 1 bar 1 bar
Electrical connection
Supply voltage * *
Connected load * *
Vacuum pump
Capacity 21 m
3
/h 21 m
3
/h
Oil 0.5 litre 0.5 litre
Type of mineral oil VM32 VM32
Ambient temperature mineral oil 5 to 30°C** 5 to 30°C**
Type of synthetic oil Foodmax Air 32 Foodmax Air 32
Ambient temperature synthetic oil -10 to 40°C** -10 to 40°C**
*See machine plate.
**For different temperatures, please contact your dealer.
