Operation 37
No. Element Explanation
2. Functions These functions are active or inactive. If a function is
active, it is displayed in a blue shade. If a function is
inactive, it is displayed in a grey shade.
3. Function active/inactive The selected function is marked with a green circle.
The name and current value of this function will appear
on the screen.
If the + functions are activated, the + is indicated
in colour. If these functions are not active, they are
displayed in a grey shade.
4. Menu The machine settings can be adjusted via the Menu
pictogram at the left of the function overview.
1. Press the
▲
or
▼
buttons to select the desired program.
2. Press the
◄
or
►
buttons to view the functions.
3. After selecting the desired function, press Enter to view and adjust the function settings.
Users can view the pre-set configuration and the owner is also authorised to change it.
4. Select the Machine Settings menu and press Enter to adjust the machine settings.
This menu can only be accessed by the owner. See Guideline for Function Values on page
43 for the possible limit values of the function values.
6.7.2.1 Programming the ACS Control Using the PC
You can import labels and programs from a USB stick by inserting the stick into the USB port of
your machine. You can create the data to be imported using the online software that is available on
the Support section of our website: http://www.henkelman.com/en/vacuum-packaging/advanced-
control-system.
Follow the steps below to create a program or label:
1. Click on the link of the LX Software.
2. Click on Select a program or label you want to change to start a new program. You can
also click on Select a file to import to import existing programs and/or labels from the
machine.
3. Select the program or label you want to change and click the button Go.
4. Enter all the information you need.
5. Click on Save to save the program or label.
Each program and label should be stored separately using the Save button.
Once you finish all programs and labels, you can export them:
6. Click on Export to export programs or labels.
• Click on Programs to save all programs.
• Click on Labels to save all labels.
Use an empty USB stick to export the files to your machine.
