Operation 28
6.2.2 Importing/Exporting Data
Data such as programs and labels can be imported and exported via the USB connection.
6.2.3 Data Log ID
The control system is provided with the option to store the production information. The data log is
stored in lined entries. Each entry consists of:
• Date
• Time
• User initials
• Selected program and settings
• Selected label
• Number of cycles
A new entry is stored when:
• A different user logs in.
• The program or program settings are changed.
The data log is stored as a .txt file. You can then export the data log to a USB stick, see Exporting
Data Log on page 29.
6.2.3.1 Setting and Using the Data Log ID
This setting is disabled by default. This option can be enabled after logging in using the owner
code. 5 possible users can be set:
• Owner
• Four other users:
∘
User 2: 3821
∘
User 3: 5718
∘
User 4: 6982
∘
User 5: 9217
1. Log in using the owner code (1324).
You will be granted access to the relevant settings.
2. Within the menu, go to Settings > Data log ID and select ON.
From this moment on, the data will be logged.
3. Assign initials to the user codes (maximum 2 characters).
a. At User, select the desired user code.
b. Enter the initials of the user at Name.
The initials of the user will be displayed in the data log.
The initials of the user must be set. If this is not the case, it cannot be traced who
operated the machine.
