Appendices 65
Set as time-controlled
Prog no. 1 2 3 4 5 6 7 8 9 10
Vacuum 25 s 20 s 15 s 10 s 30 s 25 s 20 s 20 s 15 s 30 s
Gas OFF OFF OFF OFF 5 s 5 s 10 s 15 s 15 s OFF
Seal 2.2 s 2.2 s 2.2 s 2.2 s 2.5 s 2.5 s 2.5 s 2.5 s 2.5 s 2.5 s
Seal 2 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s 3.5 s
Soft-air 3 s OFF 8 s 3 s OFF OFF 2 s OFF OFF 3 s
Example programs of the ACS control system
Prog Vacuum Vacuum+ Seal Soft-air Type of product
1. 99.8% OFF 2.2 s 3 s Solid products
2. 97% N/A 2.2 s OFF
Liquids/liquid-
containing products
3. 99.8% OFF 2.2 s 8 s Fragile/sharp products
4. 99.8% 4 s 2.2 s 3 s
Product that may
contain entrapped air
Set as senor-controlled or controlled by Liquid Control sensor
Prog no. 1 2 3 4 5 6 7 8 9 10
Vacuum 99.8% 97% 99.8% 99.8% 99.5% 99.5% 99.5% 90% 95% 90%
Vacuum+ OFF OFF 4 s 15
Gas OFF OFF OFF OFF OFF 60% OFF OFF OFF OFF
Seal 2.2 s 2.2 s 2.2 s 2.2 s 2.5 s 2.5 s 3.5 s 3.5 s 2.5 s 2.5 s
Seal 2 2.2 s 2.2 s 2.2 s 2.2 s 2.5 s 2.5 s 4.0 s 3.5 s 2.5 s 2.5 s
Soft-air 3 s OFF 8 s 3 s 5 s OFF OFF 5 s 5 s 5 s
Set as senor-controlled or controlled by Liquid Control sensor
Prog no. 11 12 13 14 15 16 17 18 19 20
Vacuum 99.8% 99.8% 99.8% 99.8% 99.5% 99.8% 90% 95% 95% 99.8%
Vacuum+ OFF OFF 5 s 5 s 5 s OFF
Gas 50% 40% OFF 70% 70% OFF 68% OFF OFF OFF
Seal 2.5 s 2.5 s 2.0 s 2.0 s 2.0 s 2.0 s 2.0 s 2.0 s 2.0 s 2.0 s
Seal 2 2.5 s 2.5 s 2.0 s 2.0 s 2.0 s 4.0 s 2.0 s 2.0 s 2.0 s 4.0 s
Soft-air OFF OFF OFF 5 s OFF OFF OFF OFF OFF OFF
