Diatron Abacus + - Spare Parts List

Diatron MI PLC
rev 1.09
76
9. SPARE PARTS
CODE
NAME
AP104
Abacus+ plastic front panel
APX104
Front panel (Abacus+, excl. keyboard)
AP132
Foil keyboard
A133
HVB board with inverter (complete)
AP136
LCD display
A137
Lamp for LCD
AP140
Amplifier board (Abacus+, complate)
J156
Power supply
AP157
Mains switch
AP730
Loudspeaker
J100
PPB board (complete)
AP170
IDEEPROM board
J112
Control board (COMB 4.12)
J113
Control board for DIMMPC
A192
DIMMPC (CPU)
A195
DIMMPC safe ring
AP300
XY needle movement block (complete)
A301
Timing belt for XY block
A302
Stepper motor
A303
Bearing for XY block
A304
Timing pulley for X (mounted)
A305
Timing pulley for Y (mounted)
A306
Gear for Y opto
AP307
H&V motor opto board (complete)
A308
Opto switch I.
A309
Opto switch II.
A310
Head washer
AP311
Aspirator tip
A313
Seeger ring (D 19)
A314
Seeger ring (RA5)
A321
Return pulley for XY
AP400
Meas. Block excl. Amplifier (Abacus+)
A401
Cone for chambers
