2.3. Assembled Analyzer
2.3.1. Abacus+
Front Panel
Rear panel:
240x128 dots
Graphic LCD
Built-in thermal
printer (optional)
START button
Function keys
Serial Port
USB slave port
Warning labels
USB ports
Power switch
12V DC inlet
Foil keypad
PS/2 external
keyboard port
Reagent inlets
