10.2.6.Serial Protocol 1.7
Receiver sends that it is ready to receive now.
<ENQ>
Abacus+ sends acknowledge.
<ACK>
Abacus+ sends INIT next time to initiate link (there is data to send):
<SOH>AI<STX>Abacus+<HT>2.22<HT>20011005<HT>135212<ETX>30<EOT>
Receiver sends acknowledge:
<ACK><SPACE>A
Abacus+ sends DATA package:
<SOH>BD<STX>SNO<HT>152<LF>DATE<HT>19980715<LF>TIME<HT>114500<LF>
SID<HT>2<LF>PID<HT>26<LF>NAME<HT>JOE
SMITH<LF>MODE<HT>0<LF>WRN<HT>0<LF>
PM1<HT>12<LF>PM2<HT>204<LF>RM1<HT>51<LF>WM1<HT>23<LF>WM2<HT>57<LF>
WM3<HT>92<LF>PARN<HT>22<LF>P01<HT> 6.6<HT>0<LF>P02<HT>4.29<HT>0<LF>
P03<HT> 167<HT>0<LF> ... P21<HT> 8.2<HT>0<LF>P22<HT> 5.3<HT>0<LF>
<ETX>7C<EOT>
Receiver acknowledges DATA transmission, and requests for RBC package:
<ACK>RB
Abacus+ sends RBC package:
<SOH>CR<STX>SNO<HT>152<LF>DATE<HT>19980715<LF>TIME<HT>114500<LF>
SID<HT>2<LF>PID<HT>26<LF>CHN<HT>256<LF>9<HT>16<HT>26<HT> ...
1<HT>0<ETX>F2<EOT>
Receiver acknowledges RBC transmission, and requests for WBC package:
<ACK>WC
Abacus+ sends WBC package:
<SOH>DW<STX>SNO<HT>152<LF>DATE<HT>19980715<LF>TIME<HT>114500<LF>
SID<HT>2<LF>PID<HT>26<LF>CHN<HT>256<LF>0<HT>15<HT>84<HT> ...
5<HT>3<ETX>69<EOT>
Receiver acknowledges WBC transmission, and closes the link.
<ACK><SPACE>D
It is possible to request for PLT histogram, but it is not shown in this example.
