Full scale and resolution of histograms:
PLT 50 fl, 1 fl x 50/256
RBC 200 fl, 1 fl x 200/256
WBC 400 fl, 1 fl x 400/256
Note 8:
Flags for individual parameters. See page 4, remark 4
Note 9:
Warning flags, see page 3, remark 1.
Note 10:
Options flag
Option (mask) Displayed Meaning
0x0001 PREDIL sample was run in pre-diluted mode
0x0002 RBCEXT sample was run in RBC extended mode (not used in HMII code)
0x0004 WBCONLY sample was run in WBC only mode - RBC related values filled with
0.0
Note 11:
Probe voltages, max and min values for separate measurements. Each value is stored on 1 byte.
Actual Probe Voltage of given measurement can be calculated as PrVxxxx * 50V /1024.
Note 12:
Age_unit = (Age > 128) ? MONTH : YEAR;
if (Age_unit == MONTH) Age_of_patient = Age - 128;
else Age_of_patient = Age;
Note: depending on database settings, either BirthDate, or Age gets filled.
LimitsLow, LimitsHigh and Param match in their structure, they contain values for parameters in the
order below (indices go from 0 to MaxParams-1):
WBC RBC HGB HCT MCV MCH MCHC PLT PCT MPV PDWsd
PDWcv/PDW RDWsd RDWcv/RDW LYM MID GRA LYMp MIDp GRAp
RBCt
WBCt WBCt2
Units can be found on page 4, note 3.
'Flags' has the same order, but contains values 0..5 each referring to the corresponding parameter
'Flags' field value interpretation can be found on page 4, note 4
