OPERATOR’S MANUAL
GAC® 2100 Grain Analysis Computer (Blue, Gray, Agri Models)
11001-1688-201609
52 INSTRUMENT SETUP
To Configure the Communications Ports
(Basic entry procedure – Followup to specific subject for finishing details):
1. From the Main menu, select the 4 key (Setup menu) and then the 7
key (COM menu).
–The Communications menu appears with seven active choices
and one non-active selection.
2. Choose the desired function by selecting the key number next to the
choice. The Enter Access Code screen appears.
3. Enter the access code and then select the Enter key.
– The selected COM screen appears ready for editing.
4. Proceed with the necessary editing of the selection.
The selections are:
– COM port select
– COM1 or COM2 format
– COM1 or COM2 serial data setup
– COM1 or COM2 control lead setup
Figure 42
Accessing the COM Menu
To Configure COM PORT SELECT:
Press the 1 key on the Communications menu:
1. After completing steps 1 through 4 from the basic entry procedure, edit
the configuration.
– Four items appear on the menu for editing and configuring output
information of both ports (COM1 and COM2).
– Each item may be set to NONE, COM1, COM2 or COM1/COM2
(both ports) using the Left/Right Arrow keys to cycle through the
choices.
– The pointer in front of each item can be moved with the Up/Down
Arrow keys.
SELECT ITEM NUMBER
(NEXT PAGE: STATUS)
SETUP MENU
1: CLEAR COUNTER
2: ID OPTIONS
3: OUTPUT OPTIONS
4: EDIT ACCESS CODE
5: DATE/TIME MENU
6: LABELS MENU
7: COM MENU
8: SERVICE MENU
COMMUNICATIONS MENU
1: COM PORT SELECT
2: COM1 FORMAT
3: COM1 DATA SETUP
4: COM1 CONTROL
5: non-active
6: COM2 FORMAT
7: COM2 DATA SETUP
8: COM2 CONTROL
SELECT ITEM NUMBER
<more>
Enter key
Left/Right Arrow Keys
Up/Down Arrow Keys
To Next Page
