DigiDesign C24 User Manual

C|24 Guide108
Line Out 1–8
Preamps 9–16
Mic In 9–16
Line/DI In 9–16
Preamp Line Outputs 1–8
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Line Out 1
24 12 25
2 Preamp
Line Out 2
10 23 11
3 Preamp
Line Out 3
21 9 22
4 Preamp
Line Out 4
7208
5 Preamp
Line Out 5
18 6 19
6 Preamp
Line Out 6
4175
7 Preamp
Line Out 7
15 3 16
8 Preamp
Line Out 8
1142
Mic Preamp Inputs 9–16
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Mic In 9
24 12 25
2 Preamp
Mic In 10
10 23 11
3 Preamp
Mic In 11
21 9 22
4 Preamp
Mic In 12
7208
5 Preamp
Mic In 13
18 6 19
6 Preamp
Mic In 14
4175
7 Preamp
Mic In 15
15 3 16
8 Preamp
Mic In 16
1142
Mic Preamp Inputs 9–16
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Line In 9
24 12 25
2 Preamp
Line In 10
10 23 11
3 Preamp
Line In 11
21 9 22
4 Preamp
Line In 12
7208
5 Preamp
Line In 13
18 6 19
6 Preamp
Line In 14
4175
7 Preamp
Line In 15
15 3 16
8 Preamp
Line In 16
1142
Mic Preamp Inputs 9–16
Channel Hot (+) Cold (–) Ground (shield)

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
