C|24 Guide30
Connection Examples for
Surround Monitoring
You can set up a surround monitoring system
using up to 6-channel input from Pro Tools.
5.1, LCRS, or Stereo input can be monitored in
the C|24 Main Monitor outputs. Stereo input
can also be monitored in the C|24 Alt Monitor
(Stereo) outputs.
An additional surround source can be moni-
tored by connecting it to the Alternate Surround
Inputs.
External stereo sources can be monitored by
connecting them to the External Stereo 1 and 2
Inputs.
You can also connect a separate cue send from
Pro Tools, and route it to the C|24 cue system
outputs.
The following tables and diagram show exam-
ples of connections for surround monitoring.
